Features and Benefits

Exceptionally high flow rate with low pressure drop
100% Integrity tested to provide a high level of confidence membranes are available
Can be sterilized by gamma irradiation or autoclaving

Applications

	SFU-GM	SS47DISC-GM	64DISC-GM	AV50-GM
Filter Media	Hydrophobic PTFE on a PET support	Hydrophobic PTFE on a PET support	Hydrophobic PTFE on a PET support	Hydrophobic PTFE on a PET support
Pore Size	0.2μm	0.2μm	0.2μm	0.2μm
Housing	Gamma stable PP	Gamma stable PP	Gamma stable PP	Gamma stable PP
Effective Filtration Area	0.72cm² 3.4cm² 4.5cm²	13.8cm²	20cm²	20cm²
Overall Length	19.0mm 22.5mm 26.1mm	47.0mm	69.5mm	83.5mm
Diameter	18.0mm 30.0mm 35.0mm	56.0mm	64.0mm	73.0mm
Inlet/Outlet Connections	Inlet: Female luer-lok Outlet: Male luer slip	1/4’’-3/8’’ Hose barb	1/4’’-1/2’’ Hose barb	1/4’’-1/2’’ Hose barb
Max. Operation Pressure	0.2MPa@20°C	0.2MPa@20°C	0.2MPa@20°C	0.2MPa@20°C
Typical Air Flow Rate (20°C)	0.5L/min@21kPa 2.1L/min@21kPa 2.9L/min@21kPa	6.3L/min@21kPa	12.4L/min@21kPa	9.0L/min@21kPa
Bubble Point	≥0.11Mpa(60%IPA)	≥0.11Mpa(60%IPA)	≥0.11Mpa(60%IPA)	≥0.11Mpa(60%IPA)
Sterilization	Gamma irradiation 25kGy recommended	- Gamma irradiation 25kGy recommended 50kGy maximum - Autoclaving	- Gamma irradiation 25kGy recommended 50kGy maximum - Autoclaving	- Gamma irradiation 25kGy recommended .50kGy maximum - Autoclaving
Biological Safety	Meets USP Biological Reactivity Test, in vivo, for Class VI-121°C Plastics.

Filter Media	Hydrophobic PES 0.2μm	Hydrophobic PVDF 0.2μm	Hydrophobic PTFE 0.2μm
Filter Structure Components	Polypropylene
Max. Differential Pressure	Forward: 4 bar	Forward: 2 bar	Forward: 1.5bar
Bacterial Retention	Retention of 10⁷ CFU/cm² Brevundimonas diminuta (ATCC®19146) according to ASTM F838.
Bacterial Endotoxin	<0.25EU/mL, according to LAL Test
Component Material Toxicity	Meets USP Biological reactivity test for Class VI-121℃ Plastics
Sterilization Method	-Gamma Irradiation: 25 kGy recommend 50 kGy maximum -Autoclaved for 3 cycles of 60 minutes at 121℃. (No in-line steam sterilization)		-Gamma Irradiation 25 kGy recommend 50kGy maximum -Autoclaved for 20 cycles of 30 minutes at 121℃. (No in-line steam sterilization)
