H-SCF-A Sanitary Filter Housing specifically designed as a single-round filter housing for low volume liquid filtration. It is part of the H-SCF Filter Housing Series.

Strongly recommended for use in life science filtration applications, it meets sanitary requirements and GMP standards. Features include mechanical polishing with a Ra of 0.3µm, easy-to-clean, and thorough drainage, which eliminates concerns about remaining liquids. In addition, electro-polishing finish is also an available option.

Design Features

• Quality surface finishing - Internal Ra: 0.3µm; External Ra: 0.4µm. Sanitary design prevents entrapment or build-up of contaminants. All electro-polishing is also available.
• Vent & Drain: Threaded sleeve is separated by a stepped thread so that the connection tube will not wave when in draining or venting operation.
• Enlarged vent and drain - internal diameter connects with an 8mm tube.
• Quick-release closure clamp allows for quick disassembly – our sectional closure clamps increase pressure endurance by 20% compared to normal clamps.
• When running at high operating pressure, quick-release closure clamps provide perfecting sealing for PTFE o-rings. Max. Operating Pressure can reach 10 bar.
• Adjustable nut on the legs allows for filter length to be adjusted.
